The Cell-Phone Radio Jammer SINTIS CPJTMVIP-300 is designed to use in vehicles and emits radio jamming barrage signals in the frequency bands of the cell telephone systems. The radio jamming signals cover the whole frequency band and they cannot be eliminated by frequency adjustments. The radio jamming signals that get into the receivers of the cell telephones are quasi noisy. Their structure does not allow them to be eliminated with of amplitude or frequency manipulations (restrictions or filtration).
The jammer has an automatic protection system, which ensures its flawless operation. This system monitors the operation modes of the transmitting modules and the normal emission of the correspondent antennas keeping the controlled parameters in safe ranges. If the operation modes are changed to unsafe values /for example malfunction of the cooling system, etc./ the protection system shuts down the corresponding module.
The indication system shows to the operator that the jammer is working properly and makes the operator feel confident. It monitors if the power supply is normal and if the antennas operate normally, etc.The security of the working personnel is guaranteed according to the Bulgarian standards BDS 14525-90 and BDS 17137-90, the European Union standard SAR and the NATO standard STANAG 2345.
| FREQUENCY RANGE | GSM /800/900; GSM /1800/1900; 3G; ISM /900/2400/5800; GSM/E /900; WCDMA /900/2100; DCS /1800; UMTS /2100; SATELLITE (1520÷1670) MHZ – (OPTIONAL); SATELLITE (2400÷2500) MHZ – (OPTIONAL). |
| SUBRANGES | 8 (OPTIONAL UP TO 10); |
| TOTAL OUTPUT POWER | ≥ 720 W (OPTIONAL UP TO 900 W); |
| OUTPUT POWER PER FREQUENCY RANGE | ≥ 90 W PER FREQUENCY RANGE; |
| INTERFERENCE TYPE | FAST RANDOM SCANNING (FRS); |
| INTERFERENCE KIND | BARRAGE; |
| POWER SUPPLY | 20÷28V (DC); 95 ÷ 265V/50HZ (AC) |
| TEMPERATURE RANGE | -30/+55 °C; |
| INTERNAL VENTILATION | AIR COOLING; |
| AUTO TEST | PERMANENT AUTO-DIAGNOSIS FOR EACH FREQUENCY RANGE; |
| CONTROLS/INDICATORS | SYSTEM ZEROIZE FUNCTION; VSWR SELF-CONTROL AND AUTOPROTECT SYSTEM; THERMO AUTOPROTECT SYSTEM; UNDER AND OVER VOLTAGE AUTOPROTECT SYSTEM; FREQUENCY RANGE STATUS INDICATOR; SECURE ON/OFF SWITCH; PERMANENT AUTODIAGNOSIS FOR EACH FREQUENCY RANGE. |
| JAMMING DISTANCE (REFERENCE DATA) | > 120 М |
